Metal Decking Clips

Metal decking clips are key connectors between metal floor decking and steel beams, and their wind resistance directly determines the safety of the roof system. Wind suction tests conducted in accordance with the AS 4040.3 standard showed that when the buckle withstood a negative pressure of 3.8,000 N per square meter, the connection did not slip or detach. Its ultimate pull-out bearing capacity reached 4.2,000 N, which is 2.3 times that of ordinary self-tapping screw connection solutions. At the same time, the fatigue vibration test was run 500,000 times in accordance with the ISO 16130 standard at 15 Hz and an amplitude of plus or minus 5 mm. The preload force retention rate of the buckle was still 95% of the initial value, while the preload force of the traditional elastic clip dropped to less than 80% after 100,000 times, proving its long-term stability on steel structure roofs in areas prone to strong winds.





From the perspective of construction efficiency and anti-loosening reliability, metal floor deck buckles also have significant advantages. On-site installation statistics show that using prefabricated buckles and special press-in tools, the average installation time for each hundred buckles is only eight minutes. Compared with traditional welding fixation methods, it saves about 70% of the man-hours and completely avoids damage to the galvanized layer by welding sparks. In the vibration loosening test conducted in accordance with the GB/T 3098.13 standard, the buckle was subjected to lateral vibration at a frequency of 40 Hz for two hours. The residual clamping force percentage was 96.5%, while the conventional spring buckle was only 82%. The salt spray corrosion resistance test further confirmed that after one thousand hours of neutral salt spray spraying, only a trace amount of white rust appeared on the surface of the zinc-aluminum coating of the buckle, and the red rust area was zero. This enables it to maintain a reliable bite connection in corrosive environments such as coastal high humidity and chemical plants, and effectively prevents the floor decking from loosening and making abnormal noises during long-term use.





Get drawings from customers, or design drawings according to customers' detail requests or sample.
The two parties confirm the details of the drawings and product raw materials, surface treatment, etc.









Quote and confirm order quantity, specify all the details including trade terms,

payment terms, type of package, etc.







Design and Make tooling according to the confirmed drawing, do the modification if needed while testing.







Carry out technical assessment and analysis on product structure,

design production process, and ensure the feasibility of the process.







Make first samples and inspect them according to the drawing strictly.

Send to the customer for approval after internal approval.







Strictly produce the goods as per the drawings and first samples.

Packed well after final inspection and ship to customers.
