Terminal PCB Male Flat

The terminal PCB male flat has a rectangular shape with flat pins protruding from each end. The middle section is wider and is designed to connect with the solder pads on the PCB. This design makes installation easier while ensuring a stable and secure connection.

The pins at both ends are flat and shaped like the letter "L." This design helps with alignment and fixation during insertion, reducing the chance of errors during installation. It also improves the overall reliability of the connection.

At one end of the terminal, there's a circular hole. This hole is typically used for screws or other fasteners to secure the terminal to the PCB. This prevents the terminal from loosening due to vibrations or external forces, ensuring it stays firmly in place.

The terminal is made of metal and has a smooth surface. It's l treated with tin plating or another anti-oxidation coating. This treatment improves conductivity and protects against corrosion, allowing the terminal to perform well in various environments.

While the image doesn't provide exact dimensions, these terminals are generally small and compact. This makes them ideal for use in electronic devices where space is limited. Their small size and efficient design make them a crucial part of modern electronics.

In summary, the terminal PCB male flat is a reliable and versatile component. Its unique design, strong performance, and wide range of applications make it a valuable tool for electronic engineers. Whether in industrial equipment or consumer electronics, this terminal plays an important role in advancing technology.

Q: How can l get a sample?

A: We can provide free samples to start the project if final mass order qty is more than 200 sets.

Q: What's the lead time for a sample and for mass production?

A: 5 days lead time for samples, if a tooling needed, may be 10-15 days at most. For mass production, lead time 15-30days according to demand qty.

Q: What trade terms you can offer?

A: We can offer you whatever terms convenient for you such as EXW, FOB. CIF. CFR etc.

Q: Can you produce part according to my sample on hand? l don't have part drawing

A: Yes, we are OEM/ODM manufacturer, we can design the part according to your sample, no extra design cost needed.

Q: Can you assemble some electronic parts we provide to you on the metal enclosure we buy from you?

A: Yes, we can do assembly work on the metal products we supply to you.
