Large Aluminum L Brackets

Minimum Order Quantity ： 500 pcs
Weight Range ： 0.5g–500kg
Dimensional tolerance ： ±0.5 mm
Please provide product specifications so that we can offer specific pricing and MOQ.

Send Inquiry

Product Introduction

Large aluminum L brackets are precision extruded from 6061-T6 aluminum alloy. After 200 hours of neutral salt spray testing, there are no corrosion spots on the surface. They are suitable for high humidity or weak acid and alkali environments. When installing large equipment, a single bracket can withstand a static load of more than 3000 N, ensuring structural stability without additional reinforcement.

The shear strength of the product reaches 207 MPa, which can effectively resist lateral shear force and avoid tearing at the bolt holes. The profile section size tolerances strictly follow the EN 755-9 standard, and the width and thickness deviations are controlled within ±0.5 mm. When multiple pieces are combined, no on-site repairs are required to ensure that the frame is square. The flatness of each bracket is controlled within 0.3 mm/m, and the diagonal error does not exceed 1 mm when multiple pieces are installed together. From precision instrument bases to heavy-duty shelf supports, they can be quickly assembled and used reliably over the long term.

Drawing Design & Confirm

Get drawings from customers, or design drawings according to customers' detail requests or sample.
The two parties confirm the details of the drawings and product raw materials, surface treatment, etc.

product-1031-684

Advantages

► Reliable carrying capacity

Taking the 200×200×12 mm specification as an example, under correct installation conditions, the static vertical load can reach 3500 N (approximately 357 kg), and the safety factor exceeds 2.5. This means that even in the face of impact loads or long-term static loads, the bracket can still maintain structural stability and is widely used in scenarios with high safety requirements such as mechanical equipment bases and heavy-duty shelf supports.

► Flexible installation

The standard product has reserved through holes every 50–100 mm along both wings and is suitable for M8 to M12 bolts. The average installation time of a single piece is less than 3 minutes. There is no need for drilling or welding on site, and only an ordinary wrench is needed to complete the fixation. It is especially suitable for temporary structures, test platforms and automated transformation projects that require rapid construction or frequent layout adjustments.

► Can be processed twice

The material has moderate hardness (approximately 95 HB), supports subsequent processing such as slot milling, drilling, tapping, and bending, and is not prone to internal cracks after processing. Taking a bracket with a thickness of 15 mm as an example, M12 deep hole threads can still be stably processed, and the pullout force is not less than 25 kN. It is convenient for on-site modification or adding accessories, and meets the flexible adjustment needs under complex installation conditions.

► Rich colors

After anodizing, electrolytic coloring can be carried out, providing more than ten colors such as black, bronze, champagne, etc., with a color difference of ΔE<1.0. It meets the requirements for integrated design of equipment appearance and can obtain durable colors without additional spraying. It not only improves the overall aesthetics of medical, laboratory and high-end equipment, but also avoids the risk of contamination caused by coating peeling.

why choose us

► Global standards

The products comply with ASTM B221 and GB/T 6892 standards. The size and hole spacing are completely interchangeable with international brands. There is no need to worry about mismatched specifications when repairing imported equipment. Cross-border project procurement can reduce the difficulty of spare parts management.

► Multi-brand compatible installation

The hole position design is fully compatible with mainstream industrial aluminum profiles and mounting bases. No conversion parts required. Can directly replace steel or iron brackets on older equipment. Renovation work hours are shortened by more than 50%.

►Reliable packaging protection

Featuring separate pearl cotton compartments. Thickened carton packaging. The gross weight of a single box shall not exceed 25 kg. The transportation damage rate is less than 0.3%. Suitable for long-distance logistics or overseas export. Reduce the work of counting after receiving goods. Reduce return and exchange processing costs.

► Versatile installation tools

The standard bracket is suitable for commonly used bolts such as M8, M10, and M12. Installation is complete with just a socket wrench. No special tools are required at the construction site. No additional training is required. It takes an average worker no more than 5 minutes to get started.
