Custom Sliding T Nuts

Custom sliding T nuts for aluminum extrusion. M3–M12 and inch threads, 304/316 stainless steel, DIN 508, RoHS/REACH. Low MOQ, samples, fast quote. Upload your drawing.


Minimum Order Quantity : 2000 kg
Dimensional tolerance : ±0.1 mm
Lead Time : Around 4 week
Please provide product specifications so that we can offer specific pricing and MOQ.
Send Inquiry
Product Introduction

Joyear manufactures custom sliding T nuts for aluminum extrusion, industrial framing, automation, and DIN 508 worktables. Choose hammer-head, spring-ball, boat-shaped, or right-angle designs. Available in metric and inch threads, carbon steel, 304 stainless steel, and 316 stainless steel.

Send your drawing or sample details - get a DFM review and quote within 24 hours.



Trust Bar
Available on request : DIN 508  · RoHS · REACH · EN 10204 3.1 · ISO 9001 QMS · Salt Spray ISO 9227 · A2/A4 Stainless · Batch Traceability

product-800-500



Product Specifications



Item Details
Product Name Sliding T Nuts
Material Carbon Steel / Stainless Steel 304/316
Thread Size M3-M12
Compatible Profile 20/30/40/45 Series
Slot Width 6mm/8mm/10mm
Production Process Stamping + Threading + Surface Treatment
Finish Zinc Plating / Nickel Plating / Natural
Standard DIN 508 available on request / OEM Specification
MOQ 2000 kg
Lead Time 4 Weeks



Four Custom Sliding T Nut Types

A sliding T nut is not just a nut. In aluminum extrusion systems, dimensional compatibility is more important than strength. If the slot width, depth, head profile, or spring tension is wrong, the nut will jam, spin, or fail to lock.



Joyear engineers custom sliding T nuts around your actual profile, thread, and installation method. Whether you need a standard hammer-head nut or a spring-loaded nut for vertical assembly, we help you avoid costly fit issues.







product-567-567

Hammer-Head Sliding T Nut

Best for: Standard aluminum profile connections.
Why choose it: Easy to insert, simple to position, and cost-effective for general framing.
Custom options: Slot width, thread size, head length, material, finish.

product-520-520

Spring-Ball Sliding T Nut

Best for: Vertical or inverted installation.
Why choose it: Built-in spring and ball mechanism prevents the nut from falling out during assembly.
Benefit: Significantly improves single-person assembly efficiency.
Custom options: Spring force, ball material, thread, slot width.

product-554-554

Boat-Shaped Sliding T Nut

Best for: Profiles with curved slot bottoms, including DIN 508 worktables.
Why choose it: Matches the curved slot for a more secure fit and better load distribution.
Custom options: Curvature, length, thread, stainless steel grade.

product-509-509

Right-Angle Sliding T Nut

Best for: Long-distance positioning by sliding the nut in from the profile end.
Why choose it: Superior rigidity for heavy-duty or precision positioning.
Custom options: Angle, length, thread, material, surface treatment.

Customization Options for OEM & ODM Buyers



We manufacture to your drawing, sample, or application requirement.

product-591-405



► Thread & Fit

  • Metric: M3, M4, M5, M6, M8, M10, M12
  • Inch: 1/4-20, 5/16-18, 3/8-16
  • Left-hand thread, fine pitch, special thread



► Head & Body

  • Hammer-head, spring-ball, boat-shaped, right-angle
  • Custom length, width, height, angle
  • Spring force and ball retention tuning



► Material & Finish

  • Carbon steel: zinc plated, nickel plated, zinc-nickel, Dacromet
  • Stainless steel: 304, 316, A2, A4
  • Passivation, black oxide, polished



► Marking & Packaging

  • Laser marking, stamping, batch code
  • Bulk carton, labeled bags, barcode, private label
  • Kitting: nut + bolt + washer + instructions



► Documentation

  • Material certificate EN 10204 3.1
  • Dimensional inspection report
  • Salt spray test report ISO 9227
  • RoHS / REACH declaration
  • PPAP / FAI on request
  • NDA for custom drawings

How to Choose the Right Sliding T Nut

Use this quick selection guide

Measure your slot width

  • Common: 6 mm, 8 mm, 10 mm. Custom widths available.

01

Confirm your thread

  • Metric M3–M12 or inch 1/4-20, 5/16-18, 3/8-16.

02

Choose the head type

  • Standard assembly: hammer-head
  • Vertical/inverted assembly: spring-ball
  • Curved slot / DIN 508: boat-shaped
  • End-loading / long positioning: right-angle

03

Choose material and finish

  • Indoor: zinc-plated carbon steel
  • Outdoor / humid: 304 stainless
  • Chemical / marine: 316 stainless

04

Send your drawing

  • We review fit, tolerance, and production feasibility before quoting.

05

Quality & Compliance



We understand that  buyers need more than a product. You need documents, traceability, and compliance.



Available on request:



  • DIN 508 / DIN 787
  • A2 / A4 stainless steel
  • Inch threads: 1/4-20, 5/16-18, 3/8-16
  • ASTM / OEM specification production
  • ISO 9001 quality management system documentation
  • RoHS 2011/65/EU declaration
  • REACH SVHC declaration
  • EN 10204 3.1 material certificate
  • Salt spray test report: ISO 9227
  • Dimensional inspection report
  • Batch traceability from raw material to shipment
  • NDA for custom drawings



Price & Order



Quote and confirm order quantity, specify all the details including trade terms, payment terms, type of package, etc.



3001



Production & Shipping



Strictly produce the goods as per the drawings and first samples.

Packed well after final inspection and ship to customers.



6001

7001

8001
